RAC30-3.3SA-E-ST
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
Switching Power Supplies 30W AC/DC 3kV REG 90-264Vin 3.3Vout
PDF
/
Inventory: 6609
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Weight 305g
Technical
Operating Temperature -40°C~70°C With Derating
Packaging Bulk
Series POWERLINE RAC30-A (30W)
Size / Dimension 4.41Lx2.51W x 1.20 H 111.9mmx63.7mmx30.5mm
Feature DC Input Capable, Universal Input
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 8
ECCN Code EAR99
Type Enclosed
Applications ITE (Commercial)
Power (Watts) 30W
Max Power Dissipation 30W
Technology HYBRID
Terminal Position DUAL
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDFM-X8
Number of Outputs 1
Approval Agency CE, cURus
Efficiency 75%
Voltage - Isolation 3kV
Output Voltage 3.3V
Max Output Current 6A
Input Voltage-Nom 115V
Trim/Adjustable Output NO
Voltage - Input 90V~264VAC
Output Current 6A
Max Output Voltage 3.3V
Current - Output 1 6A
Dimensions
Height 30.6mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
