RAC30-12DA-E-ST
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER +/-12V 30W
PDF
/
Inventory: 6655
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Weight 305g
Technical
Operating Temperature -40°C~70°C With Derating
Series POWERLINE RAC30-A (30W)
Size / Dimension 4.41Lx2.51W x 1.20 H 111.9mmx63.7mmx30.5mm
Feature DC Input Capable, Universal Input
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 8
ECCN Code EAR99
Type Enclosed
Applications ITE (Commercial)
Power (Watts) 30W
Max Power Dissipation 30W
Technology HYBRID
Terminal Position DUAL
Terminal Form UNSPECIFIED
Number of Functions 1
JESD-30 Code R-PDFM-X8
Number of Outputs 2
Approval Agency CE, cURus
Efficiency 82%
Voltage - Isolation 3kV
Output Voltage 12V
Max Output Current 1.25A
Input Voltage-Nom 115V
Trim/Adjustable Output NO
Current - Output (Max) 1.25A 1.25A
Voltage - Input 90V~264VAC
Output Current 1.25A
Max Output Voltage 12V
Voltage - Output 2 -12V
Dimensions
Height 30.6mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
