RAC30-05DA-E-ST
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER +/-5V 30W
PDF
/
Inventory: 5927
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 30.6mm
Technical
Voltage - Output 2 -5V
Max Output Voltage 5V
Output Current 3A
Voltage - Input 90V~264VAC
Current - Output (Max) 3A 3A
Trim/Adjustable Output NO
Input Voltage-Nom 115V
Max Output Current 3A
Output Voltage 5V
Voltage - Isolation 3kV
Efficiency 79%
Approval Agency CE, cURus
Number of Outputs 2
JESD-30 Code R-PDFM-X8
Number of Functions 1
Terminal Form UNSPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 30W
Power (Watts) 30W
Applications ITE (Commercial)
Type Enclosed
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Not For New Designs
Feature DC Input Capable, Universal Input
Size / Dimension 4.41Lx2.51W x 1.20 H 111.9mmx63.7mmx30.5mm
Series POWERLINE RAC30-A (30W)
Packaging Bulk
Operating Temperature -40°C~70°C With Derating
Physical
Weight 305g
Mounting Type Chassis Mount
Mount Chassis Mount
