RAC15-24SA-ST
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 24V 15W
PDF
/
Inventory: 3708
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 27.6mm
Technical
Max Output Voltage 24V
Output Current 625mA
Voltage - Input 90V~264VAC
Trim/Adjustable Output NO
Input Voltage-Nom 115V
Max Output Current 625mA
Output Voltage 24V
Voltage - Isolation 3kV
Efficiency 77%
Approval Agency CE, cURus
Number of Outputs 1
JESD-30 Code R-XXMA-X8
Number of Functions 1
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Technology HYBRID
Max Power Dissipation 15W
Applications ITE (Commercial)
Type Enclosed
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Not For New Designs
Feature DC Input Capable, Universal Input
Size / Dimension 4.41Lx2.51W x 1.09 H 111.9mmx63.7mmx27.6mm
Series POWERLINE RAC15-A (15W)
Operating Temperature -25°C~70°C With Derating
Physical
Weight 208g
Mounting Type Chassis Mount
Mount Chassis Mount
