RAC15-15DA-E
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP Module, 6 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description
CONV AC/DC 2A 6.5-18VIN 3.0-5.5V
PDF
/
Inventory: 4474
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 54mm
Length 74mm
Height 22mm
Technical
Load Regulation ±3%
Line Regulation ±0.5%
Voltage - Output 2 -15V
Max Output Voltage 15V
Output Current 500mA
Voltage - Input 90V~264VAC
Current - Output (Max) 500mA 500mA
Trim/Adjustable Output NO
Input Voltage-Nom 115V
Max Output Current 500mA
Output Voltage 15V
Efficiency 77%
Approval Agency CE, cULus
Number of Outputs 2
JESD-30 Code R-XDMA-P8
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 15W
Power (Watts) 15W
Applications ITE (Commercial)
Type Enclosed
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Feature SCP
Size / Dimension 2.91Lx2.13W x 0.88 H 74.0mmx54.0mmx22.3mm
Series POWERLINE RAC15-A (15W)
Operating Temperature -40°C~70°C With Derating
Physical
Weight 0.251lb 113.85g
Package / Case 8-DIP Module, 6 Leads
Mounting Type Through Hole
Mount Through Hole
