RAC05-24SB-ST
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
Power Supply;AC-DC;24V;0.208A;90-264V In;Encapsulated;DIN Rail;5W;RAC05-A Series
PDF
/
Inventory: 3489
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount DIN Rail
Mounting Type DIN Rail
Package / Case Module
Weight 30g
Technical
Operating Temperature -25°C~70°C With Derating
Series POWERLINE RAC05-A (5W)
Size / Dimension 3.78Lx2.12W x 0.83 H 96.0mmx53.9mmx21.0mm
Feature DC Input Capable, Universal Input
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 8
ECCN Code EAR99
Type Enclosed
Applications ITE (Commercial)
Power Rating 5W
Max Power Dissipation 5W
Technology HYBRID
Terminal Position UNSPECIFIED
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 21mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XXMA-X8
Number of Outputs 1
Approval Agency CE, cURus
Efficiency 77%
Voltage - Isolation 3kV
Output Voltage 24V
Max Output Current 230mA
Input Voltage-Nom 115V
Trim/Adjustable Output NO
Voltage - Input 90V~264VAC
Output Current 417mA
Output Power 5W
Max Output Voltage 24V
Total Power Output-Max 5W
Dimensions
Height 15.16mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
