RAC05-12DA-E-ST
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER +/-12V 5W
PDF
/
Buying Options
Total Price: USD $78.27
Unit Price: USD $78.27357
≥1 USD $78.27357
≥10 USD $73.84299
≥100 USD $69.6632
≥500 USD $65.72
≥1000 USD $62
≥3000 USD $58.49057
Inventory: 2416
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 20.5mm
Technical
Total Power Output-Max 5W
Voltage - Output 2 -12V
Max Output Voltage 12V
Output Current 160mA
Voltage - Input 90V~264VAC
Current - Output (Max) 200mA 200mA
Trim/Adjustable Output NO
Input Voltage-Nom 115V
Max Output Current 200mA
Output Voltage 12V
Voltage - Isolation 3kV
Efficiency 67%
Approval Agency CE, cURus
Number of Outputs 2
JESD-30 Code R-XXMA-X8
Number of Functions 1
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Technology HYBRID
Max Power Dissipation 5W
Power (Watts) 5W
Applications ITE (Commercial)
Type Enclosed
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature DC Input Capable, Universal Input
Size / Dimension 3.78Lx2.12W x 0.83 H 96.0mmx53.9mmx21.0mm
Series POWERLINE RAC05-A (5W)
Operating Temperature -40°C~70°C With Derating
Physical
Weight 80g
Mounting Type DIN Rail
Mount DIN Rail
