RAC05-12DA
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER +/-12V 5W
PDF
/
Inventory: 7121
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 6-DIP Module
Weight 0.177lb 80.29g
Technical
Operating Temperature -25°C~70°C With Derating
Series POWERLINE RAC05-A (5W)
Size / Dimension 2.17Lx1.77W x 0.82 H 55.0mmx45.0mmx21.0mm
Feature SCP
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Type Enclosed
Applications ITE (Commercial)
Power (Watts) 5W
Max Power Dissipation 5W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Number of Functions 1
JESD-30 Code R-XDMA-P6
Number of Outputs 2
Approval Agency CE, cULus
Efficiency 67%
Output Voltage 12V
Max Output Current 200mA
Input Voltage-Nom 115V
Trim/Adjustable Output NO
Current - Output (Max) 200mA 200mA
Voltage - Input 90V~264VAC
Output Current 160mA
Max Output Voltage 12V
Voltage - Output 2 -12V
Total Power Output-Max 5W
Isolation Voltage 3kV
Line Regulation ±0.3%
Load Regulation ±0.5%
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 45mm
Length 55mm
Height 20.5mm
