RAC05-05SA-E
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module, 5 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER 5V 5W
PDF
/
Buying Options
Total Price: USD $63.12
Unit Price: USD $63.12385
≥1 USD $63.12385
≥10 USD $59.5508
≥100 USD $56.18
≥500 USD $53
≥1000 USD $50
≥3000 USD $47.16981
Inventory: 5576
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 20.5mm
Technical
Load Regulation ±0.5%
Line Regulation ±0.3%
Isolation Voltage 3kV
Total Power Output-Max 5W
Max Output Voltage 5V
Output Power 5W
Output Current 1A
Voltage - Input 90V~264VAC
Trim/Adjustable Output NO
Input Voltage-Nom 115V
Max Output Current 1A
Output Voltage 5V
Efficiency 65%
Approval Agency CE, cULus
Number of Outputs 1
JESD-30 Code R-XDMA-P6
Depth 55mm
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 5W
Applications ITE (Commercial)
Type Enclosed
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature SCP
Size / Dimension 2.17Lx1.77W x 0.82 H 55.0mmx45.0mmx21.0mm
Series POWERLINE RAC05-A (5W)
Operating Temperature -40°C~70°C With Derating
Physical
Weight 0.177lb 80.29g
Number of Pins 5
Package / Case 6-DIP Module, 5 Leads
Mounting Type Through Hole
Mount Through Hole
