CT10.241
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
Switch Mode, 8.610A DIN Rail Panel Mount Power Supply, 24V dc to 28V dc Dimension
PDF
/
Buying Options
Total Price: USD $345.46
Unit Price: USD $345.461762
≥1 USD $345.461762
≥10 USD $325.907317
≥100 USD $307.459735
≥500 USD $290.056356
≥1000 USD $273.638071
Inventory: 1271
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Min Output Voltage 24V
Total Power Output-Max 240W
Current - Output 1 10A
Max Input Voltage 480V
Min Input Voltage 380V
Max Output Voltage 28V
Output Current 10A
Voltage - Input 323V~576VAC 3 Phase
Current - Output (Max) 10.8A
Trim/Adjustable Output YES
Input Voltage-Nom 380V
Output Voltage 24V
Voltage - Isolation 500V
Efficiency 92.9%
Approval Agency cCSAus, CE, cULus, cURus
Number of Outputs 1
JESD-30 Code R-XXMA-X9
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Depth 124mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Technology HYBRID
Additional Feature ALSO REQUIRE 576VAC TO 700VAC INPUT VOLTAGE
Power (Watts) 240W
Applications ITE (Commercial)
Type Enclosed
Number of Terminations 9
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Feature Adjustable Output, Load Sharing
Size / Dimension 4.61Lx2.44W x 4.88 H 117.0mmx62.0mmx124.0mm
Series DIMENSION C (240W)
Operating Temperature 0°C~70°C With Derating
Physical
Weight 750g
Mounting Type DIN Rail
Mount Panel
Supply Chain
Factory Lead Time 2 Weeks
