2903149
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 24V 240W
PDF
/
Buying Options
Total Price: USD $158.78
Unit Price: USD $158.7784
≥1 USD $158.7784
Inventory: 257
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount DIN Rail
Mounting Type DIN Rail
Weight 1kg
Technical
Operating Temperature -25°C~70°C With Derating
Published 2009
Series TRIO
Size / Dimension 6.30Lx1.65W x 5.12 H 160.0mmx42.0mmx130.0mm
Feature Adjustable Output, DC Input Capable, Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Type Enclosed
Max Operating Temperature 70°C
Min Operating Temperature -25°C
Applications ITE (Commercial)
Power (Watts) 240W
Number of Outputs 1
Approval Agency cULus, cURus, EAC
Efficiency 91%
Voltage - Isolation 4kV
Voltage - Output 1 24V
Max Voltage Rating (AC) 264V
Current - Output (Max) 10A
Voltage - Input 85V~264VAC
Output Current 10A
Output Power 240W
Max Output Voltage 28V
Min Input Voltage 85V
Max Input Voltage 264V
Current - Output 1 10A
Min Output Voltage 24V
Max Output Power 240W
Min Input Voltage (AC) 85V
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
