2866705
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 24V 240W
PDF
/
Buying Options
Total Price: USD $501.8
Unit Price: USD $501.8024
≥1 USD $501.8024
≥10 USD $461.66032
Inventory: 44
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount DIN Rail
Mounting Type DIN Rail
Number of Pins 13
Weight 1.099961kg
Technical
Operating Temperature -25°C~70°C With Derating
Published 2010
Series Quint
Size / Dimension 4.92Lx2.36W x 5.12 H 125.0mmx60.0mmx130.0mm
Feature Adjustable Output, DC Input Capable, IP20, Load Sharing, Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Type Enclosed
Applications ITE (Commercial)
Max Power Dissipation 240W
Depth 130mm
Number of Outputs 1
Approval Agency CB, cULus, cURus
Efficiency 93%
Voltage - Isolation 4kV
Max Output Current 10A
Voltage - Output 1 24V
Voltage - Input 320V~575VAC 3 Phase 360V~575VAC 2 Phase 450V~800VDC
Output Current 10A
Output Power 240W
Max Output Voltage 29.5V
Min Input Voltage 320V
Max Input Voltage 575V
Current - Output 1 10A
Min Output Voltage 18V
Minimum Load Required No
Dimensions
Height 130.048mm
Compliance
RoHS Status RoHS Compliant
