RID-65B
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 5V 24V 68W
PDF
/
Buying Options
Total Price: USD $23.83
Unit Price: USD $23.834228
≥1 USD $23.834228
≥10 USD $22.485118
≥100 USD $21.21238
≥500 USD $20.011686
≥1000 USD $18.87894
Inventory: 1107
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mounting Type Chassis Mount
Technical
Operating Temperature -25°C~70°C With Derating
Series RID-65 (65W)
Size / Dimension 5.08Lx3.86W x 1.50 H 129.0mmx98.0mmx38.0mm
Feature Adjustable Output, Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Enclosed
Color Silver
Applications ITE (Commercial)
Number of Outputs 2
Approval Agency CB, CE, cURus, TUV
Efficiency 82%
Voltage - Isolation 3kV
Voltage - Output 1 5V
Current - Output (Max) 4A 2A
Voltage - Input 88V~264VAC 125V~373VDC
Output Current 8A
Voltage - Output 2 24V
Max Output Power 68W
Minimum Load Required Yes
Max Input Current 2A
Dimensions
Height 38.1mm
Compliance
RoHS Status ROHS3 Compliant
