NMP1K2-E#H##E-00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
NMP CONFIGURABLE POWER SUPPLY 12
PDF
/
Inventory: 3233
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Voltage - Output 2 24V
Voltage - Input 90V~264VAC 120V~370VDC
Current - Output (Max) 20A 10A 20A
Voltage - Output 1 12V
Voltage - Isolation 4kV
Efficiency 88.5%
Approval Agency CB, CE, cURus, EAC, TUV
Number of Outputs 3
Power (Watts) 720W
Applications ITE (Commercial), Medical
Type Enclosed
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Adjustable Output, Load Sharing, PFC, Remote On/Off, Remote Sense, Standby Output, Universal Input
Size / Dimension 9.84Lx5.00W x 1.61 H 250.0mmx127.0mmx41.0mm
Series NMP (1200W)
Operating Temperature -30°C~70°C With Derating
Physical
Mounting Type Chassis Mount
Supply Chain
Factory Lead Time 7 Weeks
