NMP1K2-E#E#EH-00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
NMP CONFIGURABLE POWER SUPPLY 12
PDF
/
Inventory: 2840
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type Chassis Mount
Technical
Operating Temperature -30°C~70°C With Derating
Series NMP (1200W)
Size / Dimension 9.84Lx5.00W x 1.61 H 250.0mmx127.0mmx41.0mm
Feature Adjustable Output, Load Sharing, PFC, Remote On/Off, Remote Sense, Standby Output, Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Type Enclosed
Applications ITE (Commercial), Medical
Power (Watts) 960W
Number of Outputs 4
Approval Agency CB, CE, cURus, EAC, TUV
Efficiency 88.5%
Voltage - Isolation 4kV
Current - Output (Max) 20A 20A 20A 10A
Voltage - Input 90V~264VAC 120V~370VDC
Voltage - Output 3 12V
Voltage - Output 4 24V
Compliance
RoHS Status ROHS3 Compliant
