20800003122
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
PSU, PCON 2060-48 48V/1.25A, 60W
PDF
/
Inventory: 9270
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount DIN Rail
Mounting Type DIN Rail
Technical
Operating Temperature -10°C~70°C
Size / Dimension 4.13Lx1.77W x 2.95 H 105.0mmx45.0mmx75.0mm
Feature Adjustable Output, DC Input Capable, Universal Input
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Type Enclosed
Max Operating Temperature 70°C
Min Operating Temperature -10°C
Applications ITE (Commercial)
Power (Watts) 60W
Power Rating 60W
Max Power Dissipation 60W
Number of Outputs 1
Efficiency 92%
Output Voltage 48V
Max Output Current 1A
Voltage - Output 1 48V
Current - Output (Max) 1A
Voltage - Input 85V~264VAC
Output Current 1.25A
Output Power 60W
Max Output Power 60W
Nominal Output Voltage 48V
Dimensions
Height 75mm
Length 105mm
Width 45mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
