DRP024V060W3BA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 24V 60W
PDF
/
Inventory: 2037
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount DIN Rail
Mounting Type DIN Rail
Technical
Operating Temperature -25°C~80°C With Derating
Published 2010
Series CliQ II (60W)
Size / Dimension 4.62Lx1.97W x 4.76 H 117.3mmx50.0mmx121.0mm
Feature Adjustable Output, DC Input Capable, IP20, Load Sharing, PFC, Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Type Enclosed
Max Operating Temperature 80°C
Min Operating Temperature -25°C
Applications ITE (Commercial)
Power (Watts) 60W
Max Power Dissipation 60W
Number of Outputs 1
Approval Agency CB, cCSAus, CE, cULus, cURus
Efficiency 86%
Voltage - Isolation 4kV
Output Voltage 24V
Max Output Current 2.5A
Voltage - Output 1 24V
Current - Output (Max) 2.5A
Voltage - Input 320V~600VAC 3 Phase
Dimensions
Height 117.348mm
Length 120.904mm
Width 50.038mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
