AA30D1212A
RoHS
RoHS compliant
RoHS compliantPackage 7-DIP Module, 5 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER +/-12V 30W
PDF
/
Inventory: 8946
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 7-DIP Module, 5 Leads
Weight 0.39lb 176.9g
Technical
Operating Temperature -25°C~70°C With Derating
Packaging Bulk
Published 2002
Series AA30D (30W)
Size / Dimension 3.50Lx2.50W x 0.85 H 89.9mmx63.5mmx21.7mm
JESD-609 Code e4
Feature OCP, OTP, OVP, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Enclosed
Terminal Finish GOLD OVER NICKEL
Applications ITE (Commercial)
Max Power Dissipation 30W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Number of Functions 1
JESD-30 Code R-XDMA-P7
Number of Outputs 2
Approval Agency CE, cUL, UL
Efficiency 80%
Output Voltage 12V
Max Output Current 1.3A
Voltage - Output 1 12V
Input Voltage-Nom 115V
Trim/Adjustable Output NO
Current - Output (Max) 1.3A 1.3A
Voltage - Input 85V~264VAC
Max Output Voltage 12V
Voltage - Output 2 -12V
Current - Output 1 1.3A
Max Output Power 30W
Isolation Voltage 3kV
Current - Output 2 1.3A
Line Regulation ±0.2%
Load Regulation ±2.5%
Min Input Voltage (AC) 85V
Max Input Voltage (AC) 264V
Dimensions
Height 21.59mm
Length 88.9mm
Width 63.5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
