AA04S1500A
RoHS
RoHS compliant
RoHS compliantPackage 7-DIP Module, 6 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER 15V 4W
PDF
/
Inventory: 9933
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 27mm
Length 36.5mm
Height 17.1mm
Technical
Max Input Voltage (AC) 264V
Min Input Voltage (AC) 85V
Line Regulation ±0.5%
Isolation Voltage 3kV
Max Output Power 4W
Current - Output 1 267mA
Max Output Voltage 15V
Voltage - Input 85V~264VAC 120V~370VDC
Trim/Adjustable Output NO
Input Voltage-Nom 115V
Max Output Current 267mA
Output Voltage 15V
Efficiency 76%
Approval Agency CE, UL
Number of Outputs 1
JESD-30 Code R-PDMA-P7
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 4W
Power (Watts) 4W
Applications ITE (Commercial)
Type Enclosed
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature OCP, OVP, SCP
Size / Dimension 1.44Lx1.06W x 0.67 H 36.5mmx27.0mmx17.1mm
Series AA04S (4W)
Published 2014
Packaging Bulk
Operating Temperature -25°C~60°C With Derating
Physical
Weight 0.057lb 25.85g
Package / Case 7-DIP Module, 6 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 11 Weeks
