AA04S1200A

Delta Electronics
RoHS
RoHS RoHS compliant
Package 7-DIP Module, 6 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description AC/DC CONVERTER 12V 4W
PDF
/
Buying Options
Total Price: USD $26.85
Unit Price: USD $26.84795
≥1 USD $26.84795
≥10 USD $22.02955
≥100 USD $21.3408
≥500 USD $20.653
≥1000 USD $19.96425
Inventory: 33
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case 7-DIP Module, 6 Leads
Weight 0.057lb 25.85g

Technical

Operating Temperature -25°C~60°C With Derating
Packaging Bulk
Published 2014
Series AA04S (4W)
Size / Dimension 1.44Lx1.06W x 0.67 H 36.5mmx27.0mmx17.1mm
Feature OCP, OVP, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
Type Enclosed
Applications ITE (Commercial)
Max Power Dissipation 4W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Number of Functions 1
JESD-30 Code R-PDMA-P7
Number of Outputs 1
Approval Agency CE, UL
Efficiency 76%
Output Voltage 12V
Max Output Current 333mA
Input Voltage-Nom 115V
Trim/Adjustable Output NO
Voltage - Input 85V~264VAC 120V~370VDC
Output Power 4W
Max Output Voltage 12V
Current - Output 1 333mA
Max Output Power 4W
Isolation Voltage 3kV
Line Regulation ±0.5%
Min Input Voltage (AC) 85V
Max Input Voltage (AC) 264V

Dimensions

Height 17.018mm
Length 36.5mm
Width 27mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
