VSUU-120-3.3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 3.3V 120W
PDF
/
Inventory: 2075
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height 39.116mm
Technical
Ripple Voltage (Main Out) 0.02333Vrms
Minimum Load Required No
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Voltage - Input 90V~260VAC 130V~370VDC
Max Output Current 22A
Output Voltage 3.3V
Voltage - Isolation 4.242kV
Efficiency 80%
Approval Agency CE, cURus, GS
Number of Outputs 1
Max Power Dissipation 120W
Subcategory Power Supply Modules
Power (Watts) 120W
Applications ITE (Commercial)
Type Open Frame
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Adjustable Output, DC Input Capable, PFC, Universal Input
Size / Dimension 5.00Lx3.00W x 1.54 H 127.0mmx81.4mmx39.1mm
Series VSUU-120 (120W)
Operating Temperature 0°C~70°C With Derating
Physical
Weight 380g
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 15 Weeks
