VFM40-T5245
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 5V/24V/-5V 64W
PDF
/
Inventory: 8653
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 50.8mm
Length 101.6mm
Technical
Voltage - Output 3 -5V
Total Power Output-Max 40.5W
Voltage - Output 2 24V
Voltage - Input 90V~264VAC 120V~370VDC
Current - Output (Max) 5A 1.5A 500mA
Trim/Adjustable Output YES
Input Voltage-Nom 115V
Voltage - Output 1 5V
Output Voltage 5V
Voltage - Isolation 4.242kV
Efficiency 78%
Approval Agency CE, cURus, FCC, TUV
Number of Outputs 3
JESD-30 Code R-XXMA-X9
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Technology HYBRID
Power (Watts) 64W
Type Open Frame
Number of Terminations 9
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Pbfree Code yes
Feature Adjustable Output, Universal Input
Size / Dimension 4.00Lx2.00W x 1.20 H 101.6mmx50.8mmx30.5mm
Series VFM40 (40W)
Operating Temperature 0°C~45°C With Derating
Physical
Surface Mount NO
Mounting Type Chassis Mount
