VFM40-T515
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
Switching Power Supplies ac-dc, 40W, 5 15Vdc, triple output, open PCB
PDF
/
Inventory: 1497
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Chassis Mount
Surface Mount NO
Technical
Operating Temperature 0°C~45°C With Derating
Series VFM40 (40W)
Size / Dimension 4.00Lx2.00W x 1.20 H 101.6mmx50.8mmx30.5mm
Feature Adjustable Output, Universal Input
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 9
Type Open Frame
Applications ITE (Commercial), Medical
Power (Watts) 67W
Technology HYBRID
Terminal Position UNSPECIFIED
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XXMA-X9
Number of Outputs 3
Approval Agency CE, cURus, FCC, TUV
Efficiency 78%
Voltage - Isolation 4.242kV
Output Voltage 5V
Voltage - Output 1 5V
Input Voltage-Nom 115V
Trim/Adjustable Output YES
Current - Output (Max) 5A 2.3A 500mA
Voltage - Input 90V~264VAC 120V~370VDC
Voltage - Output 2 15V
Total Power Output-Max 42W
Voltage - Output 3 -15V
Minimum Load Required Yes
Dimensions
Length 101.6mm
Width 50.8mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
