VF-D320-D1224A-CFS
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 12V 24V 320W
PDF
/
Buying Options
Total Price: USD $177.79
Unit Price: USD $177.7864
≥1 USD $177.7864
≥10 USD $172.23184
≥100 USD $166.6764
≥500 USD $161.120608
≥1000 USD $155.564816
Inventory: 1091
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 23 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Technical
Operating Temperature 0°C~70°C With Derating
Published 2012
Series VF-D320-D (300W)
Size / Dimension 7.00Lx4.00W x 1.60 H 177.8mmx101.6mmx40.6mm
Feature Adjustable Output, PFC, Universal Input
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 18
Type Enclosed
Applications ITE (Commercial)
Subcategory Power Supply Modules
Max Power Dissipation 320W
Technology HYBRID
Terminal Position UNSPECIFIED
Terminal Form UNSPECIFIED
Number of Functions 1
JESD-30 Code R-MXMA-X18
Number of Outputs 2
Approval Agency CB, CE, cURus, TUVgs
Efficiency 75%
Voltage - Isolation 3kV
Output Voltage 12V
Max Output Current 8.33A
Voltage - Output 1 12V
Input Voltage-Nom 115V
Trim/Adjustable Output YES
Current - Output (Max) 16.67A 8.33A
Voltage - Input 90V~132VAC 180V~264VAC
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE; THERMAL
Voltage - Output 2 24V
Total Power Output-Max 300W
Dimensions
Height 40.64mm
Length 177.8mm
Width 101.6mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
