PSK-S15C-5-DIN
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC-DC, 15 W, 5 VDC, SINGLE OUTPU
PDF
/
Buying Options
Total Price: USD $20.91
Unit Price: USD $20.910032
≥1 USD $20.910032
≥10 USD $19.726452
≥100 USD $18.609853
≥500 USD $17.556467
≥1000 USD $16.562708
Inventory: 2673
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type DIN Rail
Technical
Operating Temperature -40°C~70°C With Derating
Series PSK-S15C (15W)
Size / Dimension 1.45Lx1.24W x 2.99 H 36.9mmx31.5mmx76.0mm
Feature Universal Input
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Type Enclosed
Applications ITE (Commercial)
Power (Watts) 14W
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 10
Number of Outputs 1
Approval Agency CE, cURus
Efficiency 76%
Voltage - Isolation 4kV
Voltage - Output 1 5V
Current - Output (Max) 2.7A
Voltage - Input 85V~264VAC 100V~370VDC
Compliance
RoHS Status RoHS Compliant
