PDRB-10-15
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC-DC, 10 W, 15 VDC, SINGLE OUTP
PDF
/
Inventory: 8446
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type DIN Rail
Technical
Operating Temperature -20°C~71°C With Derating
Series PDRB-10 (10W)
Size / Dimension 4.49Lx0.89W x 3.54 H 114.0mmx22.5mmx90.0mm
Feature Adjustable Output, IP20, Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Type Enclosed
Applications Industrial, ITE (Commercial)
Power (Watts) 10W
Number of Outputs 1
Approval Agency CE, cULus, TUV
Efficiency 76%
Voltage - Isolation 3kV
Voltage - Output 1 15V
Current - Output (Max) 670mA
Voltage - Input 90V~264VAC 120V~375VDC
Compliance
RoHS Status ROHS3 Compliant
