PCM-400-54-CNF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 54V 220W
PDF
/
Inventory: 4615
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 23 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Technical
Operating Temperature 0°C~70°C With Derating
Published 2016
Series PCM-400 (400W)
Size / Dimension 6.00Lx4.00W x 1.57 H 152.4mmx101.6mmx39.9mm
Feature Adjustable Output, PFC, Remote On/Off, Standby Output, Universal Input
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Enclosed
Applications ITE (Commercial)
Power (Watts) 220W 400W Forced Air
Max Power Dissipation 220W
Number of Outputs 1
Approval Agency CB, CE, cURus, TUVgs
Efficiency 87%
Voltage - Isolation 3kV
Max Output Current 4.07A
Voltage - Output 1 54V
Voltage - Input 90V~264VAC
Dimensions
Height 39.878mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
