PBK-3-24
RoHS
/
Package 12-SIP Module, 6 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER 24V 3W
PDF
/
Inventory: 5489
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Length 35mm
Height 26.924mm
Technical
Ripple Voltage (Main Out) 0.04242Vrms
Load Regulation ±2.5%
Line Regulation ±1.5%
Total Power Output-Max 3W
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Output Power 3W
Voltage - Input 85V~264VAC
Trim/Adjustable Output NO
Input Voltage-Nom 115V
Voltage - Output 1 24V
Max Output Current 125mA
Output Voltage 24V
Efficiency 78%
Approval Agency CE, cULus
Number of Outputs 1
JESD-30 Code R-XSMA-T6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 3W
Subcategory Power Supply Modules
Applications ITE (Commercial)
Type Enclosed
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature OCP, SCP
Size / Dimension 1.38Lx0.43W x 1.06 H 35.0mmx11.0mmx27.0mm
Series PBK-3 (3W)
Published 2014
Operating Temperature -40°C~85°C With Derating
Physical
Weight 0.018lb 8.16g
Package / Case 12-SIP Module, 6 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 14 Weeks
