FSC-S5-15U
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 15V 5W
PDF
/
Inventory: 7414
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Technical
Operating Temperature -20°C~70°C
Published 2010
Series FSC-S5 (5W)
Size / Dimension 2.84Lx1.24W x 0.84 H 72.0mmx31.5mmx21.4mm
Feature DC Input Capable, Universal Input
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Type Enclosed
Applications ITE (Commercial)
Power (Watts) 5W
Max Power Dissipation 5W
Reach Compliance Code compliant
Number of Outputs 1
Approval Agency CE
Efficiency 77%
Voltage - Isolation 3kV
Max Output Current 330mA
Voltage - Output 1 15V
Voltage - Input 85V~264VAC
Dimensions
Height 21.336mm
Compliance
RoHS Status Non-RoHS Compliant
