VAA1005
RoHS
RoHS compliant
RoHS compliantPackage 5-DIP Module
Category Power Supplies - Board Mount / AC DC Converters
Description
Power Supply;AC-DC;5V;2A;85-132V In;Open Frame;Thru-Hole;Embedded;10W;VAA Series
PDF
/
Buying Options
Total Price: USD $19.62
Unit Price: USD $19.6152
≥1 USD $19.6152
Inventory: 32
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 5-DIP Module
Weight 35g
Technical
Operating Temperature -10°C~70°C With Derating
Published 2001
Series VAA (10W)
Size / Dimension 2.85Lx1.26W x 0.71 H 72.4mmx32.0mmx18.0mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 5
Type Open Frame
Applications ITE (Commercial)
Power Rating 10W
Technology HYBRID
Terminal Position UNSPECIFIED
Terminal Form PIN/PEG
Number of Functions 1
Depth 18mm
Reach Compliance Code unknown
JESD-30 Code R-XXMA-P5
Number of Outputs 1
Approval Agency cURus
Efficiency 76%
Output Voltage 5V
Voltage - Output 1 5V
Input Voltage-Nom 100V
Trim/Adjustable Output NO
Voltage - Input 85V~132VAC 110V~170VDC
Output Current 2A
Output Power 10W
Current - Output 1 2A
Input Current 300mA
Isolation Voltage 3kV
Line Regulation 20mV
Load Regulation 40mV
Dimensions
Height 18mm
Length 72.5mm
Width 32mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
