NFS110-7904P image
Favorite
NFS110-7904P image
Favorite
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description AC/DC CNVRTR 5.1V +/-15V -5V 80W
PDF
/
Inventory: 7674
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Technical

Minimum Load Required No
Voltage - Output 4 -5V
Voltage - Output 3 -15V
Total Power Output-Max 110W
Voltage - Output 2 15V
Voltage - Input 85V~264VAC
Current - Output (Max) 8A 4A 500mA 500mA
Trim/Adjustable Output NO
Voltage - Output 1 5.1V
Output Voltage 5.1V
Voltage - Isolation 4kV
Efficiency 70%
Number of Outputs 4
JESD-30 Code R-XXMA-X16
Number of Functions 1
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Technology HYBRID
Power (Watts) 80W 110W Forced Air
Applications Medical
Terminal Finish TIN LEAD
Type Open Frame
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Adjustable Output, DC Input Capable, Universal Input
JESD-609 Code e0
Size / Dimension 7.00Lx4.25W x 1.80 H 177.8mmx108.0mmx45.7mm
Series NFS110 (110W)
Published 2005
Operating Temperature 0°C~70°C With Derating

Physical

Surface Mount NO
Mounting Type Chassis Mount
