NFS110-7604P
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CNVRTR 5.1V +/-15V -5V 80W
PDF
/
Inventory: 1409
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Minimum Load Required No
Voltage - Output 4 -5V
Voltage - Output 3 -15V
Voltage - Output 2 15V
Voltage - Input 85V~264VAC
Current - Output (Max) 8A 4A 500mA 500mA
Voltage - Output 1 5.1V
Voltage - Isolation 3kV
Efficiency 70%
Approval Agency CE
Number of Outputs 4
JESD-30 Code R-XSMA-N16
Pin Count 16
Terminal Position SINGLE
Power (Watts) 80W 110W Forced Air
Applications ITE (Commercial)
Type Open Frame
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Adjustable Output, DC Input Capable, Universal Input
Size / Dimension 7.00Lx4.25W x 1.80 H 177.8mmx108.0mmx45.7mm
Series NFS110 (110W)
Published 2007
Packaging Bulk
Operating Temperature 0°C~70°C With Derating
Physical
Surface Mount NO
Mounting Type Chassis Mount
