LCP1521SRL
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Circuit Protection / TVS - Thyristors
Description
THYRISTOR 100A 8SOIC
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8272
≥1 USD $0.8272
≥10 USD $0.71896
≥100 USD $0.497728
≥500 USD $0.415906
≥1000 USD $0.353954
Inventory: 11767
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Packaging Tape & Reel (TR)
Series LCP
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Capacitance 35pF
Voltage - Rated DC 150V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LCP15
Pin Count 8
Operating Supply Voltage 3V
Number of Elements 1
Temperature Grade INDUSTRIAL
Current - Peak Pulse (10/1000μs) 30A
Peak Pulse Current 100A
Reverse Standoff Voltage 150V
Max Repetitive Reverse Voltage (Vrrm) 175V
Telecom IC Type SURGE PROTECTION CIRCUIT
Hold Current 150mA
Dimensions
Length 4.9mm
Width 3.9mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
