TPD3E001DRYR

Texas Instruments
RoHS
RoHS RoHS compliant
Package 6-UFDFN
Category Circuit Protection / TVS - Diodes
Description TVS DIODE 5.5V 6SON
PDF
/
Buying Options
Total Price: USD $0.43
Unit Price: USD $0.4312
≥1 USD $0.4312
≥10 USD $0.36608
≥100 USD $0.254232
≥500 USD $0.198475
≥1000 USD $0.161322
≥3000 USD $0.144206
Inventory: 22197
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Thickness 500μm
Width 1mm
Length 1.45mm
Height 600μm

Technical

Breakdown Voltage 11V
Test Current 10mA
Direction Unidirectional
Peak Pulse Power 90W
Reverse Standoff Voltage 5.5V
Peak Pulse Current 10A
Voltage - Reverse Standoff (Typ) 5.5V Max
Clamping Voltage 105.5V
Max Reverse Leakage Current 1nA
Power Line Protection Yes
Leakage Current 1nA
Interface USB
Number of Channels 3
Configuration SINGLE
Working Voltage 5.5V
Number of Elements 1
Operating Supply Voltage 5.5V
Pin Count 6
Base Part Number TPD3E001
Depth 1mm
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology AVALANCHE
Subcategory Transient Suppressors
Capacitance 1.5pF
Applications General Purpose
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Steering (Rail to Rail)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA

Physical

Diode Element Material SILICON
Number of Pins 6
Surface Mount YES
Package / Case 6-UFDFN
Mounting Type Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
