SM30T42AY image
Favorite
SM30T42AY image
Favorite
RoHS
RoHS RoHS compliant
Package DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description STMICROELECTRONICS SM30T42AY TVS Diode, Transil SM30TY Series, Unidirectional, DO-214AB, 2 Pins
PDF
/
Buying Options
Total Price: USD $0.65
Unit Price: USD $0.652305
≥1 USD $0.652305
Inventory: 1364
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Technical

Max Breakdown Voltage 42V
Non-rep Peak Rev Power Dis-Max 3000W
Breakdown Voltage 42V
Unidirectional Channels 1
Peak Pulse Power 3kW
Reverse Standoff Voltage 36V
Peak Pulse Current 48.4A
Clamping Voltage 58.1V
Power - Peak Pulse 3000W 3kW
Voltage - Breakdown (Min) 40V
Power Line Protection No
Configuration SINGLE
Polarity Unidirectional
Number of Elements 1
Base Part Number SM30T
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Applications Automotive
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101, SM30TY, TRANSIL?
Packaging Cut Tape (CT)
Operating Temperature -55°C~175°C TJ

Physical

Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 7 months ago)
