BZW04-10
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 10.2VWM 21.7VC DO15
PDF
/
Buying Options
Total Price: USD $0.93
Unit Price: USD $0.92815
≥1 USD $0.92815
≥10 USD $0.7619
≥100 USD $0.73815
≥500 USD $0.7144
≥1000 USD $0.69065
Inventory: 20010
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 6.75mm
Diameter 3.53mm
Technical
Number of Unidirectional Channels 1
Reverse Breakdown Voltage 11.4V
Capacitance @ Frequency 1550pF @ 1MHz
Breakdown Voltage 11.4V
Test Current 1mA
Direction Unidirectional
Peak Pulse Power 400W
Max Surge Current 24A
Reverse Standoff Voltage 10.2V
Peak Pulse Current 106A
Clamping Voltage 21.7V
Voltage - Clamping (Max) @ Ipp 16.7V
Max Reverse Leakage Current 5μA
Power Line Protection No
Case Connection ISOLATED
Element Configuration Single
Leakage Current 5μA
Number of Elements 1
Operating Supply Voltage 10.2V
Pin Count 2
Base Part Number BZW04
Terminal Form WIRE
Technology AVALANCHE
Voltage - Rated DC 10V
Power Rating 400W
Subcategory Transient Suppressors
Capacitance 1.55nF
Additional Feature UL RECOGNIZED
Applications General Purpose
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Terminal Finish Matte Tin (Sn)
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series BZW04, TRANSIL?
Packaging Tape & Box (TB)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-204AC, DO-15, Axial
Mounting Type Through Hole
Mount Through Hole
