IRGP4263D1PBF

Infineon Technologies
RoHS
/
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description Tube Through Hole RoHS Compliant IGBT Transistor 2.1V @ 15V 48A 90A 325W 170ns
PDF
/
Inventory: 5990
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Through Hole
Package / Case TO-247-3
Supplier Device Package TO-247

Technical

Operating Temperature -40°C~175°C TJ
Packaging Tube
Published 2016
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Input Type Standard
Power - Max 325W
Reverse Recovery Time 170ns
Voltage - Collector Emitter Breakdown (Max) 650V
Current - Collector (Ic) (Max) 90A
Test Condition 400V, 48A, 10Ohm, 15V
Vce(on) (Max) @ Vge, Ic 2.1V @ 15V, 48A
Gate Charge 145nC
Current - Collector Pulsed (Icm) 192A
Td (on/off) @ 25°C 70ns/140ns
Switching Energy 2.9mJ (on), 1.4mJ (off)

Compliance

RoHS Status RoHS Compliant
