IRG5K50HF12A
RoHS
/
Package POWIR? 34 Module
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
IGBT MOD 1200V 100A POWIR 34
PDF
/
Inventory: 8358
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Input Capacitance (Cies) @ Vce 6.2nF @ 25V
NTC Thermistor No
Vce(on) (Max) @ Vge, Ic 2.6V @ 15V, 50A
Input Capacitance 6.2nF
Voltage - Collector Emitter Breakdown (Max) 1200V
Collector Emitter Breakdown Voltage 1.2kV
Current - Collector Cutoff (Max) 1mA
Max Collector Current 100A
Collector Emitter Voltage (VCEO) 2.6V
Input Standard
Power - Max 390W
Configuration Half Bridge
Max Power Dissipation 390W
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2014
Operating Temperature -40°C~150°C TJ
Physical
Package / Case POWIR? 34 Module
Mounting Type Chassis Mount
Mount Chassis Mount
