STW23NM50N
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 500V 17A TO-247
PDF
/
Buying Options
Total Price: USD $1.88
Unit Price: USD $1.88005
≥1 USD $1.88005
≥10 USD $1.5428
≥100 USD $1.49435
≥500 USD $1.4459
≥1000 USD $1.39745
Inventory: 584
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-247-3
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tube
Series MDmesh? II
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Resistance 190mOhm
Terminal Finish Tin (Sn)
Subcategory FET General Purpose Power
Technology MOSFET (Metal Oxide)
Terminal Position SINGLE
Base Part Number STW23N
Pin Count 3
Number of Elements 1
Configuration SINGLE WITH BUILT-IN DIODE
Power Dissipation-Max 125W Tc
Operating Mode ENHANCEMENT MODE
Power Dissipation 125W
Turn On Delay Time 6.6 ns
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 190m Ω @ 8.5A, 10V
Vgs(th) (Max) @ Id 4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 1330pF @ 50V
Current - Continuous Drain (Id) @ 25°C 17A Tc
Gate Charge (Qg) (Max) @ Vgs 45nC @ 10V
Rise Time 19 ns
Drain to Source Voltage (Vdss) 500V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±25V
Fall Time (Typ) 29 ns
Turn-Off Delay Time 71 ns
Continuous Drain Current (ID) 17A
Threshold Voltage 3V
Gate to Source Voltage (Vgs) 25V
Pulsed Drain Current-Max (IDM) 68A
DS Breakdown Voltage-Min 500V
Avalanche Energy Rating (Eas) 254 mJ
Dimensions
Height 20.15mm
Length 15.75mm
Width 5.15mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
