IXFH32N50
RoHS
/
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 500V 32A TO-247AD
PDF
/
Buying Options
Total Price: USD $1.31
Unit Price: USD $1.31385
≥1 USD $1.31385
≥10 USD $1.07825
≥100 USD $1.04405
≥500 USD $1.0108
≥1000 USD $0.9766
Inventory: 17272
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-247-3
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Published 2000
Series HiPerFET?
JESD-609 Code e1
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 3
ECCN Code EAR99
Resistance 150mOhm
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Additional Feature AVALANCHE RATED
Subcategory FET General Purpose Power
Voltage - Rated DC 500V
Technology MOSFET (Metal Oxide)
Current Rating 32A
Pin Count 3
Number of Elements 1
Power Dissipation-Max 360W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 360W
Case Connection DRAIN
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 150m Ω @ 15A, 10V
Vgs(th) (Max) @ Id 4V @ 4mA
Input Capacitance (Ciss) (Max) @ Vds 5700pF @ 25V
Current - Continuous Drain (Id) @ 25°C 32A Tc
Gate Charge (Qg) (Max) @ Vgs 300nC @ 10V
Rise Time 42 ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±20V
Fall Time (Typ) 26 ns
Turn-Off Delay Time 110 ns
Continuous Drain Current (ID) 32A
Threshold Voltage 4V
Gate to Source Voltage (Vgs) 20V
Drain to Source Breakdown Voltage 500V
Dual Supply Voltage 500V
Recovery Time 250 ns
Nominal Vgs 4 V
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
