BDX34A
RoHS
/
Package TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole PNP Single Bipolar (BJT) Transistor 750 @ 4A 3V -10A 70W 60V
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.264
≥1 USD $0.264
Inventory: 1050
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Continuous Collector Current -10A
hFE Min 750
Collector Base Voltage (VCBO) 60V
Collector Emitter Saturation Voltage 2.5V
Collector Emitter Breakdown Voltage 60V
Vce Saturation (Max) @ Ib, Ic 2.5V @ 8mA, 4A
JEDEC-95 Code TO-220AB
Current - Collector Cutoff (Max) 500μA
DC Current Gain (hFE) (Min) @ Ic, Vce 750 @ 4A 3V
Max Collector Current 10A
Collector Emitter Voltage (VCEO) 60V
Transistor Type PNP
Polarity/Channel Type PNP
Transistor Application SWITCHING
Power Dissipation 70W
Element Configuration Single
Number of Elements 1
Base Part Number BDX34
Current Rating -10A
Max Power Dissipation 70W
Voltage - Rated DC -60V
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Bulk
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
