2N4953
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole NPN Single Bipolar (BJT) Transistor 200 @ 150mA 10V 1A 625mW 60V
PDF
/
Buying Options
Total Price: USD $0.25
Unit Price: USD $0.254006
≥1 USD $0.254006
≥10 USD $0.239626
≥100 USD $0.226064
≥500 USD $0.213267
≥1000 USD $0.201197
Inventory: 1419
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Number of Pins 3
Supplier Device Package TO-92-3
Technical
Operating Temperature -55°C~150°C TJ
Packaging Bulk
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Voltage - Rated DC 30V
Max Power Dissipation 625mW
Current Rating 1A
Base Part Number 2N4953
Number of Elements 1
Polarity NPN
Element Configuration Single
Power Dissipation 625mW
Power - Max 625mW
Transistor Type NPN
Collector Emitter Voltage (VCEO) 30V
Max Collector Current 1A
DC Current Gain (hFE) (Min) @ Ic, Vce 200 @ 150mA 10V
Current - Collector Cutoff (Max) 50nA ICBO
Vce Saturation (Max) @ Ib, Ic 300mV @ 15mA, 150mA
Collector Emitter Breakdown Voltage 30V
Voltage - Collector Emitter Breakdown (Max) 30V
Current - Collector (Ic) (Max) 1A
Collector Emitter Saturation Voltage 300mV
Collector Base Voltage (VCBO) 60V
Emitter Base Voltage (VEBO) 5V
hFE Min 200
Dimensions
Height 5.33mm
Length 5.2mm
Width 4.19mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
