MS3022

Microsemi
RoHS
/
Package M
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - RF
Description Trans GP BJT NPN 45V 0.2A 4-Pin Style M210
PDF
/
Inventory: 3818
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Technical

Collector-Base Capacitance-Max 3.2pF
Highest Frequency Band L B
Collector Base Voltage (VCBO) 45V
Frequency - Transition 2GHz
Gain 7 dB
Collector Emitter Breakdown Voltage 45V
Max Collector Current 200mA
Collector Emitter Voltage (VCEO) 45V
Polarity/Channel Type NPN
Case Connection BASE
Power Dissipation-Max 7W
Configuration SINGLE
Number of Elements 1
Pin Count 2
Terminal Form FLAT
Terminal Position RADIAL
Min Operating Temperature -65°C
Max Operating Temperature 200°C
ECCN Code EAR99
Number of Terminations 2
Packaging Bulk

Physical

Number of Pins 4
Package / Case M
Mount Chassis Mount, Screw

Supply Chain

Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
