UPA801T-A
RoHS
/
Package 6-TSSOP, SC-88, SOT-363
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - RF
Description
RF TRANS 2 NPN 12V 4.5GHZ SOT363
PDF
/
Inventory: 5064
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Noise Figure (dB Typ @ f) 1.2dB @ 1GHz
Continuous Collector Current 100mA
hFE Min 70
Emitter Base Voltage (VEBO) 3V
Collector Base Voltage (VCBO) 20V
Frequency - Transition 4.5GHz
Collector Emitter Breakdown Voltage 12V
DC Current Gain (hFE) (Min) @ Ic, Vce 70 @ 7mA 3V
Max Collector Current 100mA
Collector Emitter Voltage (VCEO) 12V
Transistor Type 2 NPN (Dual)
Element Configuration Single
Polarity NPN
Base Part Number UPA801
Max Power Dissipation 200mW
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Bulk
Operating Temperature 150°C TJ
Physical
Number of Pins 6
Package / Case 6-TSSOP, SC-88, SOT-363
Mounting Type Surface Mount
Mount Surface Mount
