100SP4T6B11M1REH

E-Switch
RoHS
RoHS RoHS compliant
Package /
Category Switches / Toggle Switches
Description Toggle Switches 0.4VA @ 20V (AC/DC) (On)-Off-(On) Sldr
PDF
/
Buying Options
Total Price: USD $6.92
Unit Price: USD $6.924235
≥1 USD $6.924235
≥192 USD $2.763655
≥480 USD $2.670439
≥960 USD $2.6258
Inventory: 1330
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Contact Plating Gold
Mount Panel
Mounting Type Panel Mount
Insulation Material DIALLYL PHTHALATE
Housing Material STAINLESS STEEL
Actuator Material Brass, Chrome Plated
Center Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY

Technical

Operating Temperature -30°C~85°C
Packaging Bulk
Published 2005
Series 100
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Termination Style Solder Lug
Voltage - Rated AC 20V
Body Length or Diameter 12.7mm
Body Breadth 6.858 mm
Actuator Type Flat Anti-Rotation
Circuit SPDT
Switch Function Mom-Off-Mom
Panel Cutout Dimensions Circular - 6.35mm Dia
Contact Resistance 0.01mOhm
Electrical Life 40,000 Cycles
Illumination Non-Illuminated
Switch Type TOGGLE SWITCH
Bushing Thread 1/4-40
PCB Hole Count 3
Contact Function (ON)-OFF-(ON)
Bushing Length 0.354 inch
Contact (AC) Max Power Rating R Load 0.4VA@20VAC

Dimensions

Body Height 8.89mm
Length - Termination 0.156 inch
Actuator Length 12.30mm

Compliance

RoHS Status ROHS3 Compliant
