100SP1T6B11M7QEH
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SPDT 5A 120V
PDF
/
Inventory: 6161
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 12.30mm
Length - Termination 0.225 inch
Body Height 21.8186mm
Technical
Bushing Length 0.297 inch
PCB Hole Count 5
Contact Voltage(AC)-Max 250V
Contact (AC) Max Rating R Load 2A@250VAC
Contact Current(AC)-Max 2A
Bushing Thread 1/4-40
Switch Type TOGGLE SWITCH
Illumination Non-Illuminated
Electrical Life 40,000 Cycles
Contact Voltage(DC)-Max 28V
Contact Current(DC)-Max 5A
Contact Resistance 0.01mOhm
Panel Cutout Dimensions Circular - 6.35mm Dia
Switch Function On-On
Circuit SPDT
Actuator Type Flat Anti-Rotation
Body Breadth 12.7 mm
Body Length or Diameter 6.858mm
Voltage - Rated AC 120V
Termination Style PC Pin
Current Rating 5A
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 28V
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 100
Published 2008
Packaging Tray
Operating Temperature -30°C~85°C
Physical
End Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
Center Contact Material COPPER ALLOY
Actuator Material Brass, Chrome Plated
Housing Material STAINLESS STEEL
Insulation Material DIALLYL PHTHALATE
Mounting Feature THROUGH HOLE-RIGHT ANGLE
Surface Mount NO
Mounting Type Panel Mount, Right Angle, Vertical
Contact Plating Silver
Supply Chain
Factory Lead Time 10 Weeks
