7411SD9V4QE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Switch Toggle ON ON ON 4PDT Round Lever PC Pins 5A 250VAC 28VDC PC Mount with Bracket
PDF
/
Buying Options
Total Price: USD $31.26
Unit Price: USD $31.258531
≥1 USD $31.258531
≥10 USD $29.48918
≥100 USD $27.819979
≥500 USD $26.245262
≥1000 USD $24.759688
Inventory: 6584
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Contact Plating Silver
Mount Brackets, Through Hole
Mounting Type Through Hole
Housing Material Stainless Steel
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series 7000
Feature Jumper needed to achieve triple throw
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Orientation Straight
Depth 21.59mm
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Standard Round
Circuit DP3T
Switch Function On-On-On
Max Voltage Rating (AC) 250V
Max Current Rating 5A
Electrical Life 40,000 Cycles
Throw Configuration 4P, 4PDT, DP3T
Illumination Non-Illuminated
Max Voltage Rating (DC) 28V
Illumination Type Illuminated, Non-Illuminated
Bushing Thread Unthreaded
Dimensions
Length 16.26mm
Actuator Length 12.45mm
Compliance
RoHS Status ROHS3 Compliant
