88865155
RoHS
/
Package 100
Category Industrial Automation and Controls / Time Delay Relays
Description
CROUZET AUTOMATION 88 865 155 TIMER, FLIP/FLOP
PDF
/
Inventory: 7693
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Silver
Mount DIN Rail
Mounting Type DIN Rail
Package / Case 100
Technical
Published 2001
Series TLR1
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Screw
Max Operating Temperature 60°C
Min Operating Temperature -20°C
Voltage - Rated DC 24V
Voltage - Supply 24V~240VAC
Depth 95mm
Current Rating 8A
Termination Style Screw Terminal
Function Repeat Cycle, Twin Timer
Voltage - Rated AC 250V
Approval Agency CE, CSA, UL
Number of Contacts 1
Operating Supply Voltage 240V
Circuit SPDT (1 Form C)
Min Supply Voltage 24V
Max Current Rating 8A
Nominal Supply Current 10A
Throw Configuration SPDT
Accuracy 0.5 %
Contact Current Rating 8A
Relay Type Mechanical Relay
Power Consumption 1.5W
Contact Rating @ Voltage 10A @ 250VAC
Coil Voltage (DC) 24V
Max Supply Voltage (AC) 240V
Delay Time 0.1 Sec ~ 100 Hrs
Timing Adjustment Method Screwdriver Slot
Timing Initiate Method Input Voltage
Min Supply Voltage (AC) 24V
Nominal Input Voltage (AC) 240V
Dimensions
Height 78mm
Length 103.5mm
Width 22.5mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Ratings IP50
