T607021844BT
RoHS
RoHS compliant
RoHS compliantPackage TO-209AB, TO-93-4, Stud
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
Bulk Chassis Stud Mount Standard Recovery SINGLE SCR 4500A @ 60Hz 150mA 200V -40C~125C
PDF
/
Inventory: 4190
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Repetitive Peak Reverse Voltage 200V
Current - Off State (Max) 25mA
Voltage - On State (Vtm) (Max) 1.85V
SCR Type Standard Recovery
Non-Repetitive Pk On-state Cur 4500 A
Current - On State (It (AV)) (Max) 175A
Leakage Current (Max) 25mA
Repetitive Peak Off-state Voltage 200V
Current - Gate Trigger (Igt) (Max) 150mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 4500A @ 60Hz
Voltage - Gate Trigger (Vgt) (Max) 3V
Voltage - Off State 200V
Trigger Device Type SCR
RMS Current (Irms) 275A
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form HIGH CURRENT CABLE
Terminal Position UPPER
Subcategory Silicon Controlled Rectifiers
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2000
Packaging Bulk
Operating Temperature -40°C~125°C
Physical
Number of Pins 3
Package / Case TO-209AB, TO-93-4, Stud
Mounting Type Chassis, Stud Mount
Mount Stud
Supply Chain
Factory Lead Time 14 Weeks
