TD175N16SOFHPSA1
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
SCR MODULE 1600V 275A MODULE
PDF
/
Buying Options
Total Price: USD $40.27
Unit Price: USD $40.2724
≥1 USD $40.2724
≥10 USD $33.04385
≥100 USD $32.0112
≥500 USD $30.97855
≥1000 USD $29.9459
Inventory: 109
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Number of SCRs, Diodes 1 SCR, 1 Diode
Current - On State (It (AV)) (Max) 175A
Structure Series Connection - SCR/Diode
Current - On State (It (RMS)) (Max) 275A
Current - Hold (Ih) (Max) 400mA
Max Forward Surge Current (Ifsm) 5kA
Current - Gate Trigger (Igt) (Max) 150mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 5400A @ 50Hz
Voltage - Gate Trigger (Vgt) (Max) 2V
Max Repetitive Reverse Voltage (Vrrm) 1.6kV
Halogen Free Not Halogen Free
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2012
Packaging Tray
Operating Temperature -40°C~125°C
Physical
Package / Case Module
Mounting Type Chassis Mount
Supply Chain
Factory Lead Time 16 Weeks
